130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation

130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation

    • 130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation
    • 130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation
    • 130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation
    • 130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation
  • 130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation

    Szczegóły Produktu:

    Place of Origin: Zhangjiagang,Jiangsu,China
    Nazwa handlowa: HD Boiler
    Orzecznictwo: ISO9001,ASME,Grade A,SGS,EN,TUV
    Model Number: CFB Boiler

    Zapłata:

    Minimum Order Quantity: 1Set
    Cena: Negotiable
    Packaging Details: Seaworthy Packing
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 Sets /Year
    Skontaktuj się teraz
    Szczegółowy opis produktu
    Condition: New Structure: Fluidized bed
    Fuel: Coal / Biomass Water Circulation: Natural circulation
    Pressure: High Pressure Range of Applications: Industrial/Power station
    Specification: Customized Manufacturing Level: A
    Place Style: Vertical Burning Style: Fluidized Bed Furnace
    After-Sales Service Provided: Engineers Available To Service Machinery Overseas

    130T/H Saving Energy High Pressure Circulating Fluidized Bed Boiler wiht ASME Standard



    Product Description


    Circulating fluidized bed is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process. Circulating fluidized bed boiler with high desulfurization rate is economical.
    Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.



    Parameter

    Item Unit Specification
    Model   HD-130/3.82-M HD-130/5.3-M HD-130/9.8-M1
    Rated evaporation t/h 130
    Max.Continues evaporation t/h 150
    Rated steam pressure MPa 3.82 5.3 9.8
    Rated steam temperature 450 485 540
    Feed water temperature 172 172 215
    Fuel type Anthracite, lean coal, bituminous coal, lignite, petroleum coke, breeze, etc.
    Furnace height M 29.4
    Furnace section m2 39.22
    Number of coal feeder Unit 2
    Super heater thermostat mode   Spray desuperheater
    Unburned carbon(bituminous coal) % <6
    Pre-heater air temperature 140 168 168
    Exhaust gas temperature 145 145 145



    130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation



    Main features


    High efficiency: combustion efficiency 96~99%, carbon content in ash only about 2%, efficiency of boiler reaches 85%.
    - Suitable for various kinds of coal.
    - Load can be adjusted in the range of 25%~110%, average 5% in one minute.
    - Clean combustion and environment friendly.
    - Use lime stone mixed into the fuel for desulfuration, rate up to 84%.
    - NOx emission capacity can be controlled to 150ppm or less.
    - Ash with low carbon content can be used for cement or construction materials.



    Certifications


    130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation



    Company Introduction


    Established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port



    130T/H Circulating Fluidized Bed Coal Fired Power Plant Boiler With Natural Circulation
