35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly

35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly

    • 35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly
    • 35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly
    • 35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly
    • 35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly
  • 35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly

    Szczegóły Produktu:

    Place of Origin: ZHANGJIAGANG,CHINA
    Nazwa handlowa: HD BOILER
    Orzecznictwo: ISO9001 , SGS , TUV , ASME , EN
    Model Number: CFB BOILER

    Zapłata:

    Minimum Order Quantity: 1 set
    Cena: Negotiable
    Packaging Details: Iron Frame Packing
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 Sets per Year
    Skontaktuj się teraz
    Szczegółowy opis produktu
    Model: CFB BOILER Fuel: Coal-Fired
    Burning Style: Fluidized Bed Furnace Media: Steam and Water
    Manufacturing Level: A HS Code: 3215960855
    Usage: Power plant Port: Shanghai

    35t/h Environmental Friendly CFB Boiler Coal Fired China Professional Top Quality Industrial Application



    Product Description



    The circulating fluidized bed (CFB) is a developing technology for coal combustion to achieve lower emission of pollutants. By using this technology, up to 95% of pollutants can be absorbed before being emitted to the atmosphere.



    Parameter



    Item

    Unit

    Specification

    Model



    HD-35/3.82-M

    HD-35/5.3-M

    Rated evaporation

    t/h

    35

    Rated steam pressure

    MPa

    3.82

    5.3

    Rated steam temperature

    450

    450

    Feed water temperature

    150

    150

    Fuel type

    Anthracite, lean coal, bituminous coal, lignite, petroleum coke, breeze, etc.

    Furnace height

    M

    22

    Furnace section

    m2

    9.6

    Number of coal feeder

    Unit

    2

    Super heater thermostat mode



    Spray desuperheater

    Unburned carbon

    (bituminous coal)

    %

    <6

    Pre-heater air temperature

    140

    Exhaust gas temperature

    145



    Characteristics



    1. Steel sheet separator cyclone and air-cooled(water cooled )cyclone separator.
    2. Tail superheater area using air-cooled(water-cooled)wall enclosure.
    3. Rear fender economizer furnace wall: the guard plate frame light furnace wall, boiler tightness.
    4. Design of steel structures: Using finite element analysis software of the boiler structure was accurately calculated to ensure that the load distribution is reasonable.
    5. Optimizing a secondary air ratio can be reduced auxiliary power, strengthening extension to extend the disturbance in the furnace flue gas residence time, improve thermal efficiency of the boiler.
    6. Furnace section play, smoke long residence time in the furnace, the furnace, the furnace up speed is low, the furnace circulating volume, improve the boiler burnout rate, colleagues, greatly reducing the wear of the furnace water wall region.



    Certificate



    35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly

    ASME 'S' & 'U' STAMP



    35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly

    NB(National Board)



    Company Introduction



    Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.



    1. Fabrication area of 400,000 square meters

    2. 150 Engineers

    3. 600 Coded welders

    4. 60 Licensed Inspectors(NDT Level-III instructors)

    5. Class-A Licenses for Design and Manufacture Boiler

    6. ISO 9001:2008 Quality System

    7. ASME Certificate of Power Boilers

    8. ASME 'S','U' and NB stamp authorization



    35T/h Professional Steam CFB Boiler Utility Boiler Coal Fired Environmental Friendly
